NRG GreenBoard Panels
GreenboardTM is an Insulated Wall Panel that combines exterior cladding with insulation so designers can achieve the 6 star energy ratings that have been introduced into the building code.
GreenboardTM Insulated Wall Panel is a lightweight, energy efficient product and once coated the system provides a weather resistent, seam free rendered finish.
- Seamless finish
- Outstanding structural integrity
- Energy efficient
- BAL accredited (Bush Fire Attack)
- Fast, easy installation
- Lightweight
- Reduced building costs
- Weatherproof
- Impact resistent
- Excellent Accoustics
- Extensive choice of finishes and colour
- Minimal client disruption in renovations and extensions
- Cost effective – all inclusive packages
- Installation training for building professionals
- Technical Service & Backup, on-site demos
- Estimating & Quoting Service through NRG
- Australian owned & produced
- HIA GREENSMART member
- QMBA member
- CodeMark Accreditation – Fully Complies with BCA
- 10 year warranty
- Superior grade polystyrene – 22kg/m3
- Termite Retardant – 6320 mg/kg of Bifenthrin
- Grooved Board (designed & patented by NRG – Design Act No 158264)
- Increased Surface Tension
- Stronger, more rigid board
- Grooved both sides (cavity protection)
- All waste is recycled
- No CFC’s
- No poisonous gases
- Total R-value (m2 k/w):
- 40mm Greenboard – R1.92
- 60mm Greenboard – R2.44
- 75mm Greenboard – R2.83
- 100mm Greenboard – R3.48
6-7 Working Days
Lock Up claim quicker
Less time waiting for house to be finished (4 weeks)
Rental Saving
EXTRA LIVING AREA
7-8m2 of living area compared to Brick Veneer
CHEAPER BUILDING COSTS
30% Cheaper than rendered Brickwork
CHEAPER FOOTING COSTS DUE TO WEIGHT REDUCTION
NRG GreenboardTM 1.2kg/m2
Brickwork 90kg/m2
CUTS CARBON EMISSIONS BY UP TO 50%
Running of Air Conditioner
Saving on Electricity
THERMAL RATINGS
NRG Greenboard (75mm) 2.84R
Brickwork 1.28R
NRG keeps a constant Temperature
NRG waste is recycled
For every kg of oil used in NRG Greenboard manufacturing, about 200kg will be saved in reduced heating demands
INSULATION BATTS not essential
SOUND BATTS not necessary
Acoustic Rating RW35
THERMAL RATING FOR GREENBOARD WALL SYSTEM
Timber or Steel Frame
All insulation materials are rated for their performance in restricting heat transfer. This is expressed as an R-value which is the measure of material’s resistence to heat transfer (thermal resistence). The higher the R-value, the greater the insulating effects.
NRG Greenboard Thickness
40mm
60mm
75mm
100mm
External Air Firm
0.03 R
0.03 R
0.03 R
0.03 R
Render System
0.02 R
0.02 R
0.02 R
0.02 R
NRG GreenboardTM 75 R-value
1.30 R
1.56 R
1.95 R
2.60 R
NRG GreenboardTM 75 CRF BAL29
0.48 R
0.48 R
0.48 R
0.48 R
NRG GreenboardTM 75 CR (Cavity Release)
0.48 R
0.48 R
0.48 R
0.48 R
Breather Sisalation Wrap
0.48 R
0.48 R
0.48 R
0.48 R
Cavity and Frame
0.17 R
0.17 R
0.2 7R
0.27 R
10mm PlasterBoard
0.06 R
0.06 R
0.06 R
0.06 R
Internal Air Film
0.12 R
0.12 R
0.12 R
0.12 R
Total R-Value
2.4 R
2.92 R
3.31 R
3.96 R
Total R-value ratings were checked by: Q-Bears
PO Box 1721 Springwood Qld. 4127
Ph: 1300 304 313 or email info@qbears.com.au
